Design Vault Ep. 35 Best Of Mixed Use

TRANSCRIPT

00;00;00;02 - 00;00;05;10

DP (Doug Pat)

Let's go inside the vault. The design vault.



00;00;05;12 - 00;00;33;19

JI (Jeremy Iannucci)

So the site's essentially just a rectangle. It's the size of a full city block. So the way that we've organized the buildings around the site is in this U-shape, where they start up in the northwest corner. Move around down West Street and then below, creating a U that opens up towards the water. We try to open up the view corridors from the building and leave as much view towards the water and towards the horizon from the rest of Greenpoint as we can.



00;00;33;22 - 00;02;07;13

DP

In this special series, we're unlocking some of the most powerful conversations we've had so far. We're connecting the dots, revealing hidden gems, and unearthing insights that might have slipped by. All to spark your next big idea with brick. Whether you're looking for fresh inspiration or innovative solutions, this series is designed to fuel your creativity. So let's dive in.



Hi, I'm Doug Pat and this is Design Vault.



Today we explore mixed use developments, a type of urban design that integrates multiple uses such as residential, commercial, cultural, institutional, and entertainment into one cohesive space. Mixed use projects aim to create vibrant, interconnected communities by physically and functionally blending these diverse components, often prioritizing pedestrian friendly environments. This bonus episode highlights three remarkable mixed use projects from past episodes, emphasizing insights from architects Jeremy Iannucci, John Zimmer, and Vincente Quiroga.



We'll explore the architectural design process, construction challenges and the thoughtful use of materials, particularly brickwork, to bring these complex developments to life.



Jeremy Iannucci discussed One Java, a residential project in Greenpoint, Brooklyn. This ambitious development balances sustainability, affordability and marketability with cutting edge features.



00;02;07;19 - 00;02;36;27

JI

The site's 200ft in the North south and then between West Street and the East River around 600ft, with 40ft reserved for a waterfront esplanade. We actually pulled back even a little bit further from that, and it's located right on the waterfront in Greenpoint. There was recently a rezoning that allowed for a whole redesign of the waterfront, and our project is one of the earlier projects in that redevelopment.



00;02;36;29 - 00;02;42;19

DP

So could you give us an idea of what the scope of the project is and the programmatic requirements?



00;02;42;26 - 00;03;03;06

JI

So it's a residential project of around 834 units, encompassing a total of around 800,000ft². This also comes with a series of amenity spaces, a series of retail spaces, as well as that waterfront park and also a collection of rooftop amenities in greenspace.



00;03;03;08 - 00;03;10;03

DP

So let's talk about the building design. Stylistically, were you guys borrowing from anything locally?



00;03;10;05 - 00;03;35;06

JI

We like to think that the entire project comes from the community around it. We looked at a series of precedents in the Greenpoint neighborhood historically, and Greenpoint specifically on the waterfront, to inspire the way that we detail these facades. We have a collection of different brick styles that help to break up the massing of the building, different articulations, as well as material bricks with the two precast towers.



00;03;35;08 - 00;03;40;11

DP

So what was on the site before you guys ended up building the new architecture?



00;03;40;13 - 00;04;04;25

JI

Previously, there was a two story warehouse on the site, and it really was kind of a beautiful space in its own right before. We got the chance to tour around, before it was demolished. And I think walking around really inspired us just with these qualities of light and materials and things that were really native to the waterfront before all of this redevelopment.



00;04;04;28 - 00;04;14;08

DP

And the project, as I said, very large. Could you tell me a little bit about the zoning requirements and any challenges you guys had in terms of planning?



00;04;14;10 - 00;05;11;19

JI

So the project is as of right. It follows the zoning guidelines. The lot itself is actually split up into two different zones. So towards the inland it's mostly low rise. We had a height cap of 65ft with portions that were allowable to go up to 100. And then towards the waterfront. The zoning actually got a little more complicated where there were a few different conditions that you could meet.



It opened up these different paths for how the building could be formed. One path was a one tower scheme, which would bring you up to 360ft. And then the other was actually a two tower scheme where if one tower made it to 200ft, the other would be allowed up to 400ft. We took advantage of that in order to move more of the mass to the waterfront.



It helped gradually declined building back into the fabric of the community, and it provided more waterfront views.



00;05;11;21 - 00;05;19;14

DP

John Zimmer shared insights on The Lively, an 18 story tower in Jersey City's Powerhouse Arts District.



00;05;19;17 - 00;06;12;23

JZ (John Zimmer)

The Powerhouse Arts District in Jersey City is so named because there is a somewhat iconic powerhouse there. It had been an industrial area that was targeted for redevelopment, and they had design standards for the entire district that were meant to maintain that character. Not necessarily industrial, but loft style, focus on the arts. The entire district has a strong focus on the arts, which is part of the reason we have the black box theater in The Lively.



It's experienced a lot of new development over the course of the last decade, and it's pretty great today. When I first started going over to the powerhouse ten years ago, I'd get out of meetings and the sidewalks would be deserted, and today it feels like Brooklyn. It feels like the East Village. I mean, it is incredibly, for want of a better word, lively.



So it's a great neighborhood now, and it's all happened in the last decade. It's an exciting thing to have been a part of, honestly.



00;06;12;26 - 00;06;20;01

DP

This mixed use development includes retail spaces, a black box theater, and residential units.



00;06;20;03 - 00;07;17;00

JZ

180 residential units. Lennar is one of the biggest home builders in America, but they were mostly doing suburban subdivision work. They got into the urban markets. I can't tell you exactly one, but they were still a little bit new to it. When we took this project on and they were ambitious, they wanted to be at the absolute top of the market for a residential building in Jersey city.



And obviously, as any developer does, they wanted to maximize rentable square footage and get the most bang for their buck. And they had this requirement for the black box theater. You know, the project came with this with its approval, but it got a zoning bonus for having the theater in the base of extra height. It was a give back to the community that was written into the zoning, and we always knew it was going to be a theater, and we always knew it was going to be for a nonprofit arts group.



And that arts program as part of the building was in the DNA of the project from the very beginning, and informed a lot of the decisions moving forward became part of the personality of the building throughout, not just the theater itself, really.



00;07;17;03 - 00;07;23;18

DP

Vincente Quiroga discussed 29 Huron, a two tower development in Greenpoint, Brooklyn.



00;07;23;20 - 00;08;40;15

VQ (Vincente Quiroga)

The history of the site, you know, it's a long, narrow site. Our building massing is 100ft in the north south direction. It's over 500ft in the east west direction. So it's very distended and lengthened and narrowed. The original site was a one story warehouse, which was kind of the context of the neighborhood. I lived in that neighborhood many years ago, and that was the context.



The context is changing primarily because in a sort of Bloomberg era, there was up zoning plan, but then the 2008 crisis stalled those plans, and it took a while for that increase, zoning and development to come to fruition. And so we were part of that increased zoning for the site. In terms of the massing, we wanted to take a sense of the character that was there and honor that.



Not all the projects that we see built. Really take that into account. And we were thinking, what is the context now and what was the context in the past? So we really thought about selecting a one story podium and selecting brick as the foundation for that, and also being practical about the openings and where they are located. The emphasis for the target population would be families.



So large units, lots of two bedroom and three bedroom units, a lot of outdoor access and the views because of its waterfront proximity.



00;08;40;18 - 00;09;05;15

DP

Yeah, the site is unbelievable and you guys really take advantage of just about everything out there. It's a great project. So let's talk about the design. So first let's talk about the building stylistically. So to me it looks a lot like a very contemporary warehouse space right. So there's lots of glass. It almost appears lantern like in the photos that I saw at dusk.

It's beautiful.



00;09;05;18 -  00;09;34;00

VQ

The choice of the materials was very specific. The neighborhood has a unique grid orientation to the world, and so it captures the light in the sunrise and sunset, in particular the brick. We chose to be a rough molded brick with a dark mortar, and the metal panel has a mica flake to it that captures the light and changes throughout the day.



So some times it looks orange and coppery. Sometimes it actually looks bronze toned and it has a chocolate Sienna under glass to it.



00;09;34;07 - 00;09;42;01

DP

Each project faced unique challenges. 29 Huron is situated in a flood zone requiring innovative solutions.



00;09;42;04 - 00;10;20;28

VQ

The first story is about 17ft in height, and so there's some very high ceiling experiences there, ranging from 12 to 14ft ceilings within the amenities alone. And that also gave us the room to deal with some of the flood constraints as well. Being that the site is adjacent to the East River, the predicted flood zones right now are anywhere from 5 to 6ft above grade.



So that was a challenge and a constraint early on where we had to coordinate. We certainly decided we weren't going to excavate because of the high water table. So some of the functions that you would put in the cellar, we put a grade, but we often had to elevate the critical services six feet above where you normally would place them.



00;10;21;01 - 00;10;27;26

DP

So I'm curious, when you're digging that close to the water, do you get a lot of water, a lot of groundwater coming in when you're creating your foundation?



00;10;27;27 - 00;10;56;08

VQ

Yes. You do. Yes. Early on there was a lot of pile driving very deep anywhere from, I would say 30 or 40ft down. And those piles were linked up with large caps, pile caps, and then mat foundations at the towers. The slab itself, because of, you know, you have to think more like a boat or a bathtub. The slab itself was anywhere from 24in to 18in thick at various points throughout it, and it has to resist uplift.



00;10;56;11 - 00;11;01;27

DP

Well, that's really interesting. So when you're driving piles and there's a lot of bedrock, how do you do that?



00;11;01;29 - 00;11;21;04

VQ

The nature of the historic waterfront is often landfilled. So a lot of it is just trash or sediment. Over 200 years, people just dump things in the river. And it created a new shoreline, which was often the case, as you see in lower Manhattan as well. So we knew that we were going to have to go deep to hit rock.



00;11;21;10 - 00;11;25;28

DP

So you're driving the piles then 25 or 30ft in?



00;11;25;29 - 00;12;21;29

VQ

Yeah. And another challenge relating to the waterfront edges we had to deal with actually coordinate with the marine architect because the edge condition was failing and we needed to remediate it. So we coordinated a new driving a new sheet edge along the shore to create that. The site actually is interesting in that it has a natural cove condition that other areas along the waterfront don't.



And so we recreated that in the remediation. But we also worked with the landscape architect to create this, We're obligated by zoning to create a setback for public access on the site. So they really leaned into that curved cove condition that's set back and stepped it down to the water gradually from grade, and incorporated eco concrete blocks that have various pockets that allow kind of tidepool action to happen.



And so we thought about breaking down the shoreline a little bit and not just a hard edge.



00;12;22;02 - 00;12;31;12

DP

It sounds really interesting. I mean, when somebody owns a piece of property like that and it's really sitting on debris, in many cases, it's kind of unusual.



00;12;31;14 - 00;13;07;28

VQ

I mean, we tried to find opportunities to maximize the value of the site with the two towers strategy. We put lots of valuable floor area up high and took advantage of the views. We made double the amount of corner units that you could have by having a two towers. We also separated them over 100ft apart, so that the west tower really gets out there in front of other buildings that are it's alongside the east tower is a setback for the east to kind of get around other buildings that could obscure it.



And we were actually surprised at how good the views are as it was being built. We knew it was going to be good, but it actually turned out to be better than we anticipated.



00;13;08;00 - 00;13;14;27

DP

It's really beautiful about the design as the corners are opened up, then to become porches, right? Terraces. Is that correct?



00;13;15;00 - 00;13;34;04

VQ

That's right. So as part of that is a response to some zoning constraints. At a certain height, you also had to setback in multiple directions. And one of the things that we like to do is incorporate our balconies into the building facade and not just look like appendages. So we really took advantage of that setback rule and created these covered, protected balconies.



00;13;34;07 - 00;13;44;23

DP

The Lively was also situated in a flood zone, requiring solutions such as deployable barriers, elevated critical systems and flood resistant glazing.



00;13;44;25 - 00;14;09;02

JZ

The unique topographic feature would be that it's below the 100 year flood elevation. That's always a big deal. And the sidewalks there, I think are about five feet above sea level. So flood protection resiliency, ground floor uses. How do you enter the building? How do you avoid nuisance flooding when it's not a 100 year storm? Those were all big aspects of the design of the ground floor or the pedestrian experience.



00;14;09;05 - 00;14;10;16

DP

So breakaway walls?



00;14;10;23 - 00;14;40;01

JZ

There are deployable flood barrier systems designed in. So the flood elevation is seven feet above the sidewalk. In the event of a massive tech, a hurricane Sandy kind of thing, they would deploy these flood barrier systems. I don't know if you're familiar with them, but they keep them in storage and they come out and they both enter the building, or they spread them around the building.



They can be self-supporting, and they have to be deployed in a certain amount of time because it's an emergency response system. So a big part of all the projects in this area.



00;14;40;06 - 00;14;44;17

DP

And what about zoning codes? You had mentioned you had a height issue.



00;14;44;19 - 00;15;27;12

JZ

Yeah. So the building got, I think, 65 additional feet for having the black box theater in it. That was one zoning aspect. You can see the cantilever here over the sidewalk. There was a sidewalk widening requirement in the zoning. So that made it obviously challenging. You've got 17 stories of residences coming down over a cantilever that allows the sidewalk to be wider at the base.



That was an interesting challenge. There's a little bit of parking in the building that came from the zoning. So obviously some structural challenges there as well. Whenever you're putting that many residences over the top of a parking garage. The second floor here that you see through the window, that is also designated art space in the zoning also requirement.



00;15;27;14 - 00;15;32;26

DP

So I don't do tall buildings. How many extra floors to 65ft get you?



00;15;32;29 - 00;15;59;27

JZ

I think it was basically five because the top floor is an amenity space, rooftop amenity, which was specifically permitted by the zoning bonus. I think it really made the building, the massing and the expression of these mid-range buildings is a little bit tricky. They're not as tall as they want to be to be a tall building, and they're not as low rise as they want to be to be a low rise building.



And I think the extra stories really help to give it a little bit more verticality. It's a better piece of architecture for it.



00;16;00;02 - 00;16;03;22

DP

So tell us about the building plan. You said there's a sharp corner.



00;16;03;24 - 00;16;47;10

JZ

Yeah, very acute corner. There's two lot lines and it has a corner lot. So right where you have your corner window with two exposures, there's a very acute corner and I can't remember the actual degrees. But anytime you have a building it's not just the corner that's a problem. In fact the corner isn't really a problem. You may not be able to put a sofa in that corner, but the corner per se is not a problem.



It's kind of a cool room to be inside of, but what it means is that the apartments on each of those two different streets are on different geometries. And so if you're going to have a rectilinear apartment on streets that are at such different geometries that all crashes into each other at the corner and at the corridors and at the courtyards, so it becomes very challenging to plan buildings that feel sensible and projects that have this kind of site.



00;16;47;12 - 00;16;59;02

DP

The narrow, irregular site of The Lively, demanded creative massing strategies to optimize space while meeting zoning requirements and maintaining contextual sensitivity.



00;16;59;05 - 00;18;01;13

JZ

From its get go. There was never any question it was going to be a contemporary building. As far as where we drew our inspiration from and what we were looking at, you know, I mentioned the difficulty, the massing for these midnight buildings. I think the gathering together, the window openings into these vertical slots helps to emphasize the verticality of the building.



We have this prominent gold portal for the black box theater and the building entrance, and that became an idea that we repeated throughout the facade frame, these moments on the facade. And I think generally we try to be pretty rigorous about how the facades are designed. Obviously you've got structural continuity, but then you've got what always happens in residential design is you've got living rooms that are one width and you've got bedrooms that are a different width.



And so a strictly rational grid is probably not going to serve you well for a residential building the way it does for a commercial building. So you're often trying to find a way to manage that. If your interest is fundamentally and having a kind of rigorous and rational facade, you're trying to find a way to manage those partitions hitting the wall.



00;18;01;13 - 00;18;19;27

JZ

And what does that mean? And at the same time, I think creating a facade with movement and interest and dynamism and that play on the facade, I think was always an important part. And you could say it is part of the emphasis on the arts and the theater and dance, but also obviously just an interest in creating something fresh.



00;18;19;29 - 00;18;28;25

DP

At One Java for the project prioritized views and thoughtful use of materials which elevated the design and ensured long term durability.



00;18;28;28 - 00;18;56;15

JI

So the site's essentially just a rectangle. It's the size of a full city block, and on three sides on the north, the east and the south, we have streets. And then the west side is the waterfront. It's the East River. So the way that we've organized the buildings around the site is in this U-shape where they start up in the northwest corner, move around down West Street and then below, creating a view that opens up towards the water.



00;18;56;18 - 00;18;59;18

DP

So it's really all about the views, which it should be.



00;18;59;20 - 00;19;14;19

JI

Yes, it's something that it needs to be on the waterfront as well as it is about the views back into the neighborhood. We try to open up the view corridors from the building and leave as much view towards the water and towards the horizon from the rest of Greenpoint as we can.



00;19;14;22 - 00;19;24;13

DP

So tell us a little bit about the material choices. We've got a series of different materials and colors there. What were the decisions behind that?



00;19;24;15 - 00;20;16;04

JI

The building massing itself is broken up into five unique buildings, and out of those we have two towers that are precast, and those are the buildings on the waterfront. And then inland, there are three different buildings that range from ten stories to six stories. And those three buildings are brick, and that we really wanted to draw back from a lot of our inspirations in the Greenpoint community.



There's no shortage of brick precedents there. There's beautiful buildings such as The Astral, which is this queen in red brick terracotta building. There's Saint Anthony's Church, which is red brick and limestone trim. It's really beautiful, striking building. We looked towards kind of the history of the waterfront, those manufacturing industrial buildings, and used that precedent to define these brick colors, these three different brick buildings.



00;20;16;06 - 00;20;44;28

DP

So interestingly, the facades. So we've got the shorter or we've got the less tall architecture, which are brick buildings, and the facades are a series of what I'll call punctures with spandrel. It looks like spandrel brick in between each one of these vertically in between each one of the window openings. Correct? Yes. So how many studies did you guys end up doing to decide what these facades looked like?



00;20;45;00 - 00;21;23;17

JI

Everything kind of melded together. At some point, it's hard to break it down into a number because it was just this completely iterative process where we'd look at something, we'd make a model, we draw it, we'd look at it again, we'd make another model, we draw it. And this evolved from the concept, schematic designs all the way through to the construction document development.



This idea of the different brick details that actually came from wanting to streamline the project. So we use the same details on each of the brick buildings, but we remix them in each one. We use them in a different order to create a different identity for each of these.



00;21;23;19 - 00;21;40;29

DP

I think what's really interesting about these facades too, so you separate them facades into squares or rectangles, and then they have this very well. It looks subtle in elevation from far away, but it's actually a very large construction joint in between each one of these square rectangular panels. Correct?



00;21;41;02 - 00;21;56;02

JI

Yes. We use that construction joint and we overemphasize it. We use this double soldier coursing reveal tool as a way to further break up the massing and kind of imply this subdivisions within the buildings.



00;21;56;05 - 00;21;59;01

DP

And how deep is that, is that one brick thickness?



00;21;59;04 - 00;22;00;20

JI

It's two inches.



00;22;00;20 - 00;22;11;11

DP

Two inches. It's nice because when you look at the facade, I mean, it looks quite homogenous. But if you look at it a little bit more deeply, it's separated into these squares and rectangles. It's very pretty.



00;22;11;16 - 00;22;30;20

JI

Yeah. That's the effect that we really want to go for in terms of how this fits into the fabric of Greenpoint. We like the idea of there being this large scale massing that breaks down and continues to break down the closer you get, and it relates to more of your scale relative to the way that you're viewing it.



00;22;30;22 - 00;22;52;26

DP

You know, as an aside, what's really pretty, the red brick that you guys use there, there are a lot of lighter bricks in that facade, and so it makes it look almost pink in color, but you get up close to it and you can see a lot of variations in these colors in the red colored brick, a lot of like I'll call it value, but it's light and dark red brick.



00;22;52;29 - 00;23;57;04

JI

For that facade we're using a blended brick, and we wanted that to echo some of the red brick buildings that you already see on West Street, on the waterfront. That was kind of our launching point for coming up with this brick palette. We knew that there was going to be a red brick building. We knew that it was going to be relative to those warehouses.



And then the other two bricks were kind of an offshoot that based on how we wanted to frame this story of the building as you move around the site. So to the north, there's a lighter brick. It's something that we see as a little more modern. We try to keep the tones of the brick and mortar and the sills and other materials a little more homogenous.



And then on the flip side of that, on the southern street of the building, Java Street, we wanted to use something with a bit more variation. We wanted a higher contrast between the ground and the brick, a higher variability within the bricks. And that's something that we saw as a little more nostalgic to some of those worker housings and the smaller buildings that you begin to see as you move more inland.



00;23;57;07 - 00;24;41;16

DP

These mixed use projects demonstrate how brick and thoughtful architectural design can serve as a bridge between the past and future. By blending functionality with design, each project contributes to its community while addressing practical and esthetic goals.



Jeremy, John and Vincenet emphasize the importance of collaboration, innovation, and a deep understanding of site context in achieving these outcomes. Ultimately, these developments showcase how mixed use projects can create vibrant, connected urban environments, enriching neighborhoods through thoughtful integration of diverse uses and attention to detail in design and execution.
